GXC-MIPI-AR0234

GXC-MIPI-AR0234 002

GXC-MIPI-AR0234 001

GXC-MIPI-XXX 002

Onseim Global Shutter CMOS SENSOR AR0234CSSC
More flexible and powerful ISP
Frame rate：1.122 – 60 fps
Video streaming mode（Free Running）, Normal Trigger Mode
Open Source Driver and Application Demo
On Board IR-CUT Control Circuit
2lane MIPI（CSI-2）Interface
YUV422-8bit UYVY / YUYV format
29*29mm Compact Design
Support Raspberry Pi 3/3B/3B+/4B/Zero/Compute Module
Support Nvidia Jetson Nano / NX
Support Rockchip RK35XX

GXC-MIPI-IMX662

GXC-MIPI-IMX662 002

GXC-MIPI-IMX662 001

GXC-MIPI-XXX 002

SONY STARVIS SENSOR IMX662-AAQR
More flexible and powerful ISP
Frame rate：0.065 – 60 fps
Video streaming mode, Normal Trigger Mode, Sync Mode(Multi-camera synchronization)
Open Source Driver and Application Demo
On Board IR-CUT Control Circuit
2lane MIPI（CSI-2）Interface
YUV422-8bit UYVY / YUYV format
29*29mm Compact Design
Support Raspberry Pi 3/3B/3B+/4B/Zero/Compute Module
Support Nvidia Jetson Nano / NX
Support Rockchip RK35XX

MV-MIPI-GMAX4002M

MV-MIPI-GMAX4002M-01

MV-MIPI-IMX265M 02

MV-ADP-CMOUNT 01

MV-ADP-CMOUNT 02

1/1.7” 2.45M Pixel,4um unit cell size, Gpixel Global Shutter CMOS SENSOR GMAX4002-AVM
MIPI CSI-2 Interface
Mono-8、Mono-10，Mono-12 Data Format
Support 2×2 Binning mode
Video streaming mode（Free Running）, Normal Trigger Mode, Pulse Trigger Mode
Hardware and Software trigger source
Support trigger frame number, interval, delay, trigger filter function
Strobe synchronization
ROI
USER Output
Flexible frame rate settings
Support Raspberry PI platform
Support Nvidia Jetson platform
Support RockChip RK35xx platform

Industrial Camera / Machine Vision Camera

learn more product infomation…

MV-MIPI-SC130M

MV-MIPI-SC130M 01

MV-MIPI-SC130M 02

MV-MIPI-IMX178M-CM 01

MV-ADP-CMOUNT 02

1/2.7” 1.3M Pixel SmartGS^® Global Shutter CMOS SENSOR
MIPI CSI-2 Interface
Mono-8、Mono-10 Data Format
Video streaming mode（Free Running），Trigger mode
Hardware and Software trigger source
Support trigger frame number, interval, delay, trigger filter function
Strobe synchronization
ROI
USER Output
Flexible frame rate settings
Support Raspberry PI platform
Support Nvidia Jetson platform

MV-MIPI-IMX296M

MV-MIPI-IMX296M 01

MV-MIPI-IMX296M 02

MV-ADP-CMOUNT 01

MV-ADP-CMOUNT 02

1/2.9” 1.55M Pixel SONY IMX296LLR-C Pregius Global Shutter CMOS SENSOR
MIPI CSI-2 Interface
Mono-8、Mono-10 Data Format
Video streaming mode（Free Running），Trigger mode
Hardware and Software trigger source
Support trigger frame number, interval, delay, trigger filter function
Strobe synchronization
ROI
USER Output
Flexible frame rate settings
Support Raspberry PI platform
Support Nvidia Jetson platform

MV-MIPI-IMX265M

MV-MIPI-IMX265M 01

MV-MIPI-IMX265M 02

MV-ADP-CMOUNT 01

MV-ADP-CMOUNT 02

1/1.8” 3.15M Pixel SONY IMX265LLR-C Pregius Global Shutter CMOS SENSOR
MIPI CSI-2 Interface
Mono-8、Mono-10，Mono-12 Data Format
Video streaming mode（Free Running），Trigger mode
Hardware and Software trigger source
Support trigger frame number, interval, delay, trigger filter function
Strobe synchronization
ROI
USER Output
Flexible frame rate settings
Support Raspberry PI platform
Support Nvidia Jetson platform

MV-MIPI-IMX264M

MV-MIPI-IMX264M 01

MV-MIPI-IMX265M 02

MV-ADP-CMOUNT 01

MV-ADP-CMOUNT 02

2/3” 5.06M Pixel SONY IMX264LLR-C Pregius Global Shutter CMOS SENSOR
MIPI CSI-2 Interface
Mono-8、Mono-10，Mono-12 Data Format
Video streaming mode（Free Running），Trigger mode
Hardware and Software trigger source
Support trigger frame number, interval, delay, trigger filter function
Strobe synchronization
ROI
USER Output
Flexible frame rate settings
Support Raspberry PI platform
Support Nvidia Jetson platform

MV-MIPI-IMX178M

MV-MIPI-IMX178M-01

MV-MIPI-IMX178M-CM 01

MV-MIPI-X-JETSON NX 02

MV-MIPI-X-RPI B 04

MV-MIPI-X-RPI IOB 04

MV-MIPI-X-RPI Z 02

1/1.8” 6M Pixel SONY IMX178LLJ-C Rolling Shutter CMOS SENSOR
MIPI CSI-2 Interface
Mono-8、Mono-10，Mono-12 Data Format
Video streaming mode（Free Running），Trigger mode，High-speed continuous trigger mode
Hardware and Software trigger source
Support trigger frame number, interval, delay, trigger filter function
Strobe synchronization
ROI
USER Output
Flexible frame rate settings
Support Raspberry PI platform
Support Nvidia Jetson platform

RAW-MIPI-SC132M

RAW-MIPI-SC132M_01

RAW-MIPI-SC132M_02

1/4” 1.3M Pixel SmartGS^® SC132GS Global Shutter CMOS Sensor
MIPI CSI-2 Interface
Mono-8、Mono-10 Data Format
Video streaming mode，Trigger mode
Hardware and Software trigger source
Support trigger delay, trigger count function
Strobe synchronization
ROI
Flexible frame rate settings
Support Sensor Direct Access mode
Support Raspberry PI platform
Support Nvidia Jetson platform

Video Streaming Camera

learn more product infomation…

VEYE-MIPI-IMX462

Starlight MIPI Camera

VEYE-MIPI-IMX462

SONY STARVIS SENSOR IMX462LQR-C
Build in ISP Process
Open Source Driver and Application Demo
On Board IR Sync Circuit
On Board IR-CUT Control Circuit
2lane MIPI（CSI-2）Interface
YUV422-8bit UYVY format
DOL WDR
Single board
Support Raspberry Pi 3/3B/3B+/4B/Zero/Compute Module
Support Nvidia Jetson Nano / TX2 / NX
Support AVNET i.MX 8M Maaxboard
Support MYiR i.MX 8M (MYD-JX8MX)
Support Google Coral

VEYE-MIPI-IMX385

Starlight MIPI Camera

VEYE-MIPI-IMX385 001_1920-1080

SONY STARVIS SENSOR IMX385LQR-C
Pixel Unit cell size 3.75*3.75um, Diagonal 8.35 mm
Build in ISP Process
Open Source Driver and Application Demo
On Board IR Sync Circuit
On Board IR-CUT Control Circuit
2lane MIPI（CSI-2）Interface
YUV422-8bit UYVY format
DOL WDR
Single board
Support Raspberry Pi 3/3B/3B+/4B/Zero/Compute Module
Support Nvidia Jetson Nano / TX2 / NX
Support AVNET i.MX 8M Maaxboard
Support MYiR i.MX 8M (MYD-JX8MX)
Support Google Coral

CS-USB-IMX307

Starlight Camera

CS-USB-IMX307带线缆

SONY STARVIS SENSOR IMX307LQD-C
Build in ISP Process
USB2.0 Interface / UVC Protocol
Support YUY2 / MJPG / H.264 Video Format
On Board IR Sync Circuit
On Board IR-CUT Control Circuit
Digital WDR
